Related products

•
  Jerguson

  Jerguson 125 Series Valve Sets for Tubular Glass Gages, Tubular Glass Level Gages, Liquid Level Valves for Tubular Glass Gages

  These tubular glass gage cocks represent years of experience in the manufacture of gage cocks and offer a variety of types and connections to suit all requirements.

  The Jerguson No. 125 Standard valve for tubular glass gages has a standard straight-through flow design featuring a durable cast aluminum wheel. Connections of 1/2″ or 3/4″ NPT are available for attaching the valve to the vessel. Consider this model to replace the 12-T.

  Maximum working pressure dependent on length and resultant pressure rating of glass.

•
  Jerguson

  Jerguson Magnicator WF Series Wide Magnetic Flag Liquid Level Indicators

  Jerguson recommends flag indicators for virtually all applications, therefore flags come as standard on all Magnicator® products. The Magnicator WF series of flag style liquid level indicators are the most reliable, shock resistant, longest lasting magnetic level indicators available, and now they’re also the widest! The Jerguson WF Series wide indicator flags are 1 1/2″ (38.10mm) wide, have single stainless steel stamping, a permanent magnet in each flag, and dual rotation points. At rest, each flag is strongly attracted to each adjacent flag of the same color, with an active magnetic field of 200 Gauss at the leading edges. This attraction can only be broken by a magnetic field strong enough to cause the flags to rotate.

•
  Jerguson

  Jerguson Series 40 Heavy Duty Liquid Level Gages, Reflex R-40 and Transparent T-40, Armored Flat Glass Gages

  The Jerguson Series 40 liquid level gage is used in heavy duty, high pressure process applications of 4,000 psi, or saturated steam applications requiring a 1,500 WSP rating. Jerguson Series 40 armored flat glass gages are simple, rugged instruments engineered to provide accurate liquid level readings for the life of the vessel they are installed. All liquid level flat glass gages are hydrostatically tested by Jerguson prior to shipment at 1 1/2 times the design pressure rating at 100°F (38°C).

•
  Liquid Level Instruments

  Whitman Controls L40 / L45 Series Vertical Mount Stainless Steel Liquid Level Switches

  The Whitman Controls L40 / L45 Series 1″ Cylinder Vertical Mount Stainless Steel Liquid Level Switches have both a stainless steel stem and float affording the user high performance and versatility. These levels are most commonly seen in OEM and various other industrial applications. These are used in potable water, hot water, and in various acids and solvents as the Whitman Red Seal potting compound allows the switches to be submersible to a NEMA 6 rating.
